Fractures and Boulders

Fractures and Boulders
Fractured impact melt left the interior of De Forest crater lined with boulders. LROC NAC M125650563L, image width is 720 m, North is up [NASA/GSFC/Arizona State University].

Today's Featured Image highlights a portion of the interior of De Forest crater (57 km in diameter), which is located inside the South Pole–Aitken basin. The cavity of De Forest crater exhibits prominent terraces of collapsed materials surrounding the central peak (see next WAC context image below). The topographic low, east of the central peak, was largely coated with hot impact melt which formed a hard crust as it cooled; a portion of this melt is seen in the opening image.

Fractures and Boulders Context
Context view of De Forest crater consisting of LROC WAC monochrome mosaic (100 m/pix) overlain with a colorized WAC stereo DTM (GLD100, Scholten et al., 2012). Image center is 76.92°S, 197.51°E. The LROC NAC footprint (blue box) and the location of opening image (yellow arrow) are illustrated [NASA/GSFC/Arizona State University].

Much of the area of the opening image is covered by numerous boulders, some of which are up to ~15 m across. The smooth surface extending in lower-left to upper-right is impact melt that cooled to form solid rock, and is now fractured in regular patterns along the edge. Impact melt that was splashed on the crater's walls and its central peak formed a coating that quickly cooled to solid rock. Later, it is likely that nearby moonquakes caused these brittle rock coatings to fracture, providing the source of boulders we now see on the lower reaches of the crater floor.  As you can see in the following full NAC frame, an enormous number of similar boulders are found along the smooth melt deposits on the floor of De Forest crater.

Explore this boulder-rich crater in the full NAC frame!
