Dark Patches

M1136029632L
Unusual low refectance patch in ejecta from an unnamed fresh crater. LROC NAC M1136029632L, image width is 1170 m, incidence angle is 32° [NASA/GSFC/Arizona State University].

Today's Featured Image highlights an odd shape/texture in impact ejecta. An unnamed fresh crater (~600 m in diameter) located between Mare Marginis and Mare Undarum (QuickMap link) hosts teardrop-shaped low reflectance patches in its ejecta (northwest of the crater, see next NAC context image). The larger teardrop patch in the opening picture has a sharp boundary along its western (left) edge, perhaps implying a partially elevated surface relative to the surrounding high-reflectance ejecta. Note the faint high-reflectance ray overlying this patch, indicating that the low reflectance patch was emplaced before the completion of the impact event. Similar dark patches that are smaller and less pronounced are found at the top of the opening image.

NAC context view
NAC context view of M1136029632L. Image center is 9.495°N, 79.415°E; image width is about 3.6 km.

How were these peculiar dark patches formed? If these patches are elevated, they could represent preexisting flat dark mounds that were swept by the saltating ejecta materials. Or the excavation of low-reflectance materials by the impact could have been thrown out in one direction and resulting in this unusual patch of ground. If, on the other hand, the patches are topographic lows rather than elevated, these depressions could have simply been shielded as the ejecta passed overhead. It is also possible that the topography of the rim controlled the direction of the outthrown ejecta such that there were "no ejecta" zones that resulted in the dark patches. High resolution topography would really help unravel this mystery! NAC to the rescue! The LROC targeted this area for upcoming NAC stereo pairs from which meter-scale topography will be extracted. In a few months, we will post the topography and will see if we solved the mystery!

WAC context view
Context view of the unnamed fresh crater highlighted in Today's Featured Image (denoted by the yellow arrow) in an LROC WAC monochrome mosaic (100 m/pix). Image center is 9.12°N, 79.54°E.

Explore this peculiar dark patch and surrounding terrain in the following full NAC frame!

Related posts:

Dark Splash?

Onset Diameter

Pyroclastic Trails

Layer of Pyroclastics

Excavating Deposits

Not Your Average Crater

Published by Hiroyuki Sato on 7 August 2014
