Pits Atlas: Jackson 1c
Impact Melt pit: Jackson | |
---|---|
Name | Jackson 1c |
Lat. | 22.4214 |
Long. | 196.2907 |
Desc. | Eastern of the Jackson 1 pit chain. Elliptical, with both east and west ends having a smooth slope to the floor (western end, at least, is in self-cast shadow at 45 degree incidence angle!). Center of the pit is a large block of fractured rock, rising to level with surrounding terrain. |
Types | |
Terrain | Impact Melt |
Host Feature | Jackson |
Funnel Min. Diam. | 45 |
Funnel Max. Diam. | 95 |
Inner Min. Diam. | 31 |
Inner Max. Diam. | N/A |
Azimuth | 60 |
Depth | 15.0 |
Depth 1 | 15.3 |
Depth 2 | 10.7 |
Depth 3 | 18.2 |
Best Stereo Left | M105593167L |
Best Stereo Right | M105593167L |
DTMs | |
Clipping Width | 200 |
Other IMGs | M1122318040R |
Data Warning | Depth 3 is from top of funnel. |
Entrance Ramp | Y |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | N |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | N |
In Depression | N |
Colinear Pits | Y |
Colinear Depressions | N |
Colinear Fractures | N |
