Pits Atlas: King 1b
Impact Melt pit: King | |
---|---|
Name | King 1b |
Lat. | 6.2402 |
Long. | 119.7351 |
Desc. | Elliptical pit, southeastern of a pair "separated" by a bridge. Floor slopes from ~2m below E rim to ~5m lower below the S end of the bridge. There is a cluster of 1-5m boulders under the E side of the bridge (there's a 5m-long block directly under the NE edge). No driving access, except by going under the bridge. |
Types | |
Terrain | Impact Melt |
Host Feature | King |
Funnel Min. Diam. | 21 |
Funnel Max. Diam. | 32 |
Inner Min. Diam. | 18 |
Inner Max. Diam. | 28 |
Azimuth | 120 |
Depth | 10.0 |
Depth 1 | 12.1 |
Depth 2 | 7.6 |
Depth 3 | 11.6 |
Best Stereo Left | M143839277L |
Best Stereo Right | M143839277L |
DTMs | NAC_DTM_KINGCRATER3 |
Clipping Width | 200 |
Other IMGs | |
Data Warning | Depth 2 is from rim, other depths are from bridge. |
Entrance Ramp | N |
Overhang | Y |
Nearby Pits? | Y |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | Y |
Beside Dome | Y |
In Depression | N |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | N |
