Pits Atlas: King 18
Impact Melt pit: King | |
---|---|
Name | King 18 |
Lat. | 6.6235 |
Long. | 119.9894 |
Desc. | Round/rectangular pit on the SW side of a very subtle (~2-3m?) ~70m-wide rise; N and E walls are significantly taller than S. The floor appears to slope up towards the S rim, and may form a traversable ramp. A fracture/linear depression starts ~20m S and runs ~130m SSE. King 17 is ~140m WNW, and there are several other <5m pit/collapse-looking features in the area. |
Types | |
Terrain | Impact Melt |
Host Feature | King |
Funnel Min. Diam. | 18 |
Funnel Max. Diam. | 19 |
Inner Min. Diam. | 12 |
Inner Max. Diam. | 14 |
Azimuth | 160 |
Depth | 7.0 |
Depth 1 | 9.5 |
Depth 2 | 7.5 |
Depth 3 | 4.9 |
Best Stereo Left | M128509025R |
Best Stereo Right | M128509025R |
DTMs | NAC_DTM_KINGCRATER2 |
Clipping Width | 200 |
Other IMGs | |
Data Warning | Depths 2 and 3 are from W wall, Depth 1 is from E. |
Entrance Ramp | Y? |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | Y? |
In Depression | N |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | Y |
