Pits Atlas: King 40
Impact Melt pit: King | |
---|---|
Name | King 40 |
Lat. | 6.4779 |
Long. | 119.9976 |
Desc. | Rectangular pit in a system of fractures. Not technically connected to any fractures, although there is a line of divots running WSW from the pit, passing through a similarly-sized collapse ~120m W, and joining up with a line of fractures ~180m to the W. The NW rim is a ramp from surface to floor. There's a ~2m pit 4m E of the E corner of the pit, and King 22 is ~185m NW. |
Types | |
Terrain | Impact Melt |
Host Feature | King |
Funnel Min. Diam. | 31 |
Funnel Max. Diam. | 50 |
Inner Min. Diam. | 17 |
Inner Max. Diam. | 26 |
Azimuth | 110 |
Depth | 6.0 |
Depth 1 | 6.2 |
Depth 2 | 5.6 |
Depth 3 | 4.8 |
Best Stereo Left | M128509025R |
Best Stereo Right | M128509025R |
DTMs | NAC_DTM_KINGCRATER2 |
Clipping Width | 200 |
Other IMGs | |
Data Warning | |
Entrance Ramp | Y |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | N |
In Depression | N |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | Y? |
