Pits Atlas: Klute W 4
Impact Melt pit: Klute W | |
---|---|
Name | Klute W 4 |
Lat. | 37.8581 |
Long. | 216.8911 |
Desc. | An elliptical pit at the north end of a ~60m long linear depression. Another ~60m segment start ~70 NE of the pit's segment, in line with that segment, ending when it runs into a small rise. There is another ~150m long linear depression, with some cliffs along it, ~100m to the SE. There appears to be a small boulder filling much of the south end of the pit. A slewed image (M171488353L) may be showing a few meters of overhang to the west. |
Types | |
Terrain | Impact Melt |
Host Feature | Klute W |
Funnel Min. Diam. | 12 |
Funnel Max. Diam. | 16 |
Inner Min. Diam. | 5 |
Inner Max. Diam. | 6 |
Azimuth | 10 |
Depth | >8.0 |
Depth 1 | >7.0 |
Depth 2 | >5.0 |
Depth 3 | >7.0 |
Best Stereo Left | M143201144L |
Best Stereo Right | M143201144L |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | There seems to be a lit floor at 4.2 m depth in M140840176R, but the shadow edge does not agree with the sun direction. If it is a floor, and not wall, then the depth is ~4m, but there is a deeper section. |
Entrance Ramp | N |
Overhang | Y? |
Nearby Pits? | N? |
Nearby Fractures? | N |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | N |
In Depression | Y |
Colinear Pits | N |
Colinear Depressions | N? |
Colinear Fractures | N |
