Pits Atlas: Klute W 5
Uncertain, Impact Melt pit: Klute W | |
---|---|
Name | Klute W 5 |
Lat. | 38.1018 |
Long. | 216.9323 |
Desc. | Small pit(?) on the SW side of a slight rise. Funnel is very pronounced, and south wall is a slope down to floor level (probably). Hard to make out the morphology. ~200m NW of Klute W 3, ~150m SE of a feature that appears to be a cliff cutting off the end of yet another small rise. |
Types | Uncertain |
Terrain | Impact Melt |
Host Feature | Klute W |
Funnel Min. Diam. | 14 |
Funnel Max. Diam. | 21 |
Inner Min. Diam. | 4 |
Inner Max. Diam. | 5 |
Azimuth | 140 |
Depth | 2.0 |
Depth 1 | N/A |
Depth 2 | 2.1 |
Depth 3 | N/A |
Best Stereo Left | M143201144L |
Best Stereo Right | M143201144L |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | Might be able to get multiple shadow depths, but most images are either slewed, low-res, or have the sun shining straight down the collapsed slope. |
Entrance Ramp | Y? |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | N |
Nearby Depressions? | Y |
In Dome | Y |
Beside Dome | N |
In Depression | N |
Colinear Pits | Y? |
Colinear Depressions | N |
Colinear Fractures | N |
