Pits Atlas: Klute W 6
Impact Melt pit: Klute W | |
---|---|
Name | Klute W 6 |
Lat. | 38.1256 |
Long. | 216.901 |
Desc. | Rectangular pit in a series of NE-SW-trending fractures and depressions. The NW wall is a slope from rim to floor. There's a 22m long fracture 12m NE (arguably part of the same pit- the SE rim appears continuous, though more of a slight rise than a sharp rim in the space between pit and fracture). There's another NE-SW fracture ~120m NE of Klute W 6. Klute W 2 is ~300m SSW. |
Types | |
Terrain | Impact Melt |
Host Feature | Klute W |
Funnel Min. Diam. | 29 |
Funnel Max. Diam. | 53 |
Inner Min. Diam. | 12 |
Inner Max. Diam. | 28 |
Azimuth | 55 |
Depth | 7.0 |
Depth 1 | 7.0 |
Depth 2 | 6.9 |
Depth 3 | 6.2 |
Best Stereo Left | M171495141L |
Best Stereo Right | M171495141L |
DTMs | |
Clipping Width | 400 |
Other IMGs | |
Data Warning | |
Entrance Ramp | Y |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | N |
In Depression | Y? |
Colinear Pits | Y |
Colinear Depressions | N? |
Colinear Fractures | Y |
