Pits Atlas: Lalande 12
Impact Melt pit: Lalande | |
---|---|
Name | Lalande 12 |
Lat. | -4.4275 |
Long. | 351.4436 |
Desc. | Irregular pit. "Funnel" is odd- it looks like there is an outer rim with vertical walls, in addition to the normal inner pit. On the east edge of a ~150x100m rough area (probably slightly raised, possibly a fracture field- no stereo and lack of low-Sun images make it hard to classify). There is a pair of shallow pits ~250m SE, and a complex set of fractures ~150m SW. |
Types | |
Terrain | Impact Melt |
Host Feature | Lalande |
Funnel Min. Diam. | 9 |
Funnel Max. Diam. | 11 |
Inner Min. Diam. | 4 |
Inner Max. Diam. | 8 |
Azimuth | 150 |
Depth | 11.0 |
Depth 1 | 11.3 |
Depth 2 | 9.9 |
Depth 3 | 10.6 |
Best Stereo Left | M172975608L |
Best Stereo Right | M172975608L |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | All depths might be minimums. Floor is only unambiguously visible in M109290998L, but incidence (~3 degrees) is approximately the same as emission (~2 degrees). Stereo is accidental and probably only works for manual viewing. |
Entrance Ramp | N |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | Y |
In Depression | N |
Colinear Pits | Y? |
Colinear Depressions | Y |
Colinear Fractures | Y |
