Pits Atlas: Oday 2
Impact Melt pit: Oday | |
---|---|
Name | Oday 2 |
Lat. | -30.9463 |
Long. | 158.0644 |
Desc. | Rectangular pit ~150m from the crater wall, SW wall is a nearly uninterrupted slope to surface. There are more depressions and collapses to the SW suggesting a larger partially-collapsed void space, with possible uncollapsed bridge. Subtle PRF just to the NE. Linear collapse/fracture ~65m W. |
Types | |
Terrain | Impact Melt |
Host Feature | Oday |
Funnel Min. Diam. | 16 |
Funnel Max. Diam. | 34 |
Inner Min. Diam. | 12 |
Inner Max. Diam. | 14 |
Azimuth | 25 |
Depth | 4.0 |
Depth 1 | 4.0 |
Depth 2 | 4.1 |
Depth 3 | 4.7 |
Best Stereo Left | M1250880175R |
Best Stereo Right | M1250880175R |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | All depths measured from NW wall (adjacent to PRF) |
Entrance Ramp | Y? |
Overhang | ? |
Nearby Pits? | N |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | Y |
In Depression | N |
Colinear Pits | N |
Colinear Depressions | Y |
Colinear Fractures | N |
