Pits Atlas: Stevinus 22
Impact Melt pit: Stevinus | |
---|---|
Name | Stevinus 22 |
Lat. | -32.9349 |
Long. | 53.9595 |
Desc. | Wide shallow pit. Floor is bowl-shaped. SW corner of floor almost reaches rim, but not quite. There is a 20x15m collapse, ~4m deep, 180m to the E, which only has N and S walls- the E and W are slopes from surroundings to floor. There are a couple of other depressions in line with these two pits, although they could be degraded impact craters. The eastern collapse is at the S foot of a PRF, but Stevinus 22 is not adjacent to that PRF, though it is in a possible valley between two PRFs. |
Types | |
Terrain | Impact Melt |
Host Feature | Stevinus |
Funnel Min. Diam. | 41 |
Funnel Max. Diam. | 44 |
Inner Min. Diam. | 35 |
Inner Max. Diam. | 38 |
Azimuth | 40 |
Depth | 9.0 |
Depth 1 | 7.1 |
Depth 2 | 10.1 |
Depth 3 | >8.0 |
Best Stereo Left | M1157415551R |
Best Stereo Right | M1157415551R |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | Depth 2 is from funnel to center of floor. Long axis is ~perpendicular to obvious depression trend. Stereo is accidental, and may not be useful for anything other than manual viewing. |
Entrance Ramp | N? |
Overhang | ? |
Nearby Pits? | N? |
Nearby Fractures? | N |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | N |
In Depression | Y? |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | N |
