Pits Atlas: Tharp 2
Impact Melt pit: Tharp | |
---|---|
Name | Tharp 2 |
Lat. | -30.5395 |
Long. | 145.5548 |
Desc. | A rectangular pit ~150m E of the crater wall. The floor is covered in 1-18m boulders, and there are no collapsed walls. There is a very thin fracture running 50m S from the S corner of the pit, and several more thin fractures running N-S to the east of the pit. There are a couple of large (~100m diameter) fracture-associated collapses ~120m and ~260m SE. |
Types | |
Terrain | Impact Melt |
Host Feature | Tharp |
Funnel Min. Diam. | 70 |
Funnel Max. Diam. | 91 |
Inner Min. Diam. | 56 |
Inner Max. Diam. | 88 |
Azimuth | 20 |
Depth | 24.0 |
Depth 1 | 24.0 |
Depth 2 | 27.5 |
Depth 3 | 20.3 |
Best Stereo Left | M1168585439L |
Best Stereo Right | M1168585439L |
DTMs | |
Clipping Width | 200 |
Other IMGs | M108278624L |
Data Warning | |
Entrance Ramp | N |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | Y |
Nearby Depressions? | N |
In Dome | N |
Beside Dome | N |
In Depression | N |
Colinear Pits | Y |
Colinear Depressions | N |
Colinear Fractures | Y |
