Pits Atlas: Tycho 5a
Impact Melt pit: Tycho | |
---|---|
Name | Tycho 5a |
Lat. | -42.6199 |
Long. | 348.6332 |
Desc. | Southwesternmost of a ~kilometer-long chain of pits and other collapses, and the only one in the line that does not have an obviously round-bottomed or mostly-filled-in floor (no floor is visible in available images?) . S wall may be steeply sloped, not truly vertical, or there may be a bit of floor visible in M139979870R. At the NE end of the chain, it turns into a series of fracture-associated pits. There is also a possible ~5m wide pit 25m east of this one, and Tycho 5e is out of the line of pits ~85m to the SE of Tycho 5a. |
Types | |
Terrain | Impact Melt |
Host Feature | Tycho |
Funnel Min. Diam. | 35 |
Funnel Max. Diam. | 54 |
Inner Min. Diam. | 21 |
Inner Max. Diam. | 31 |
Azimuth | 70 |
Depth | 22.0 |
Depth 1 | 21.6 |
Depth 2 | >23.0 |
Depth 3 | N/A |
Best Stereo Left | M1206074763R |
Best Stereo Right | M1206074763R |
DTMs | |
Clipping Width | 200 |
Other IMGs | M111661378L |
Data Warning | |
Entrance Ramp | Y? |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | N |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | N |
In Depression | N |
Colinear Pits | Y |
Colinear Depressions | N |
Colinear Fractures | N |
