Pits Atlas: Tycho 18
Impact Melt pit: Tycho | |
---|---|
Name | Tycho 18 |
Lat. | -43.2779 |
Long. | 347.8259 |
Desc. | Semicircular pit, floor is largely in shadow in available images. Several large boulders are visible sticking up above floor (including one ~7m tall one near the center). In a region of N-S trending fractures, but not connected to any of them |
Types | |
Terrain | Impact Melt |
Host Feature | Tycho |
Funnel Min. Diam. | 61 |
Funnel Max. Diam. | 70 |
Inner Min. Diam. | 40 |
Inner Max. Diam. | 61 |
Azimuth | 10 |
Depth | 17.0 |
Depth 1 | 17.7 |
Depth 2 | >13.0 |
Depth 3 | 17.0 |
Best Stereo Left | M1182543691L |
Best Stereo Right | M1182543691L |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | Depths, particularly 2 and 3, may be to sides of boulders, not actual floor. |
Entrance Ramp | N |
Overhang | ? |
Nearby Pits? | N |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | Y |
In Depression | N? |
Colinear Pits | N |
Colinear Depressions | N? |
Colinear Fractures | Y |
