Pits Atlas: Tycho 29a
Impact Melt pit: Tycho | |
---|---|
Name | Tycho 29a |
Lat. | -42.8468 |
Long. | 348.5424 |
Desc. | Triangular pit near the top of a PRF, northeasternmost and most vertical-walled of a line of three pits. The pits have no collapses between them, and are spaced ~12m apart. There is a set of fractures in line with these pits. |
Types | |
Terrain | Impact Melt |
Host Feature | Tycho |
Funnel Min. Diam. | 12 |
Funnel Max. Diam. | 20 |
Inner Min. Diam. | 9 |
Inner Max. Diam. | 18 |
Azimuth | 50 |
Depth | >10.0 |
Depth 1 | >10.0 |
Depth 2 | >9.0 |
Depth 3 | N/A |
Best Stereo Left | M1206074763L |
Best Stereo Right | M1206074763L |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | |
Entrance Ramp | N |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | Y |
Beside Dome | N |
In Depression | N |
Colinear Pits | Y |
Colinear Depressions | N |
Colinear Fractures | N |
