Pits Atlas: Tycho 29c
Impact Melt pit: Tycho | |
---|---|
Name | Tycho 29c |
Lat. | -42.8478 |
Long. | 348.5405 |
Desc. | Irregular pit at base of a PRF, widest and southwesternmost of the chain of three. There are several 2-6m boulders covering the floor. The south wall is a smooth slope from surface to floor. Pit is ~70m NE of nearest fractures. |
Types | |
Terrain | Impact Melt |
Host Feature | Tycho |
Funnel Min. Diam. | 35 |
Funnel Max. Diam. | 37 |
Inner Min. Diam. | 17 |
Inner Max. Diam. | 25 |
Azimuth | 50 |
Depth | 10.0 |
Depth 1 | 11.3 |
Depth 2 | 9.0 |
Depth 3 | N/A |
Best Stereo Left | M1206074763L |
Best Stereo Right | M1206074763L |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | Depths are to same point, but Depth 2 is from lower point on rim than Depth 1. |
Entrance Ramp | Y |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | Y |
Beside Dome | Y |
In Depression | Y? |
Colinear Pits | Y |
Colinear Depressions | N |
Colinear Fractures | Y |
