Pits Atlas: Wood T 1a
Impact Melt pit: Wood T | |
---|---|
Name | Wood T 1a |
Lat. | 43.8876 |
Long. | 235.754 |
Desc. | Roughly triangular pit, with a fan-shaped extension to the NE where the north half of the NE wall has collapsed (straight down, not into pit) to form a slope from surroundings to floor. Some potential tiny pits (~2m) ~10m NE of that extended section. Subtle depression to the E/NE (lowest point at edge of pit) that looks like the surroundings sagged a few meters. Possible visible west wall in slewed image (12 degrees), opposite wall from possible sag. ~150m W of Nameless A 1b. Region is a bit lumpy, but no depressions or fractures other than the two pits. |
Types | |
Terrain | Impact Melt |
Host Feature | Wood T |
Funnel Min. Diam. | 33 |
Funnel Max. Diam. | 46 |
Inner Min. Diam. | 25 |
Inner Max. Diam. | 40 |
Azimuth | 40 |
Depth | 11.0 |
Depth 1 | 11.1 |
Depth 2 | 11.3 |
Depth 3 | 10.5 |
Best Stereo Left | M143078925L |
Best Stereo Right | M143078925L |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | M193783245R and M1158545901R are lit by crater wall-shine. |
Entrance Ramp | Y |
Overhang | N? |
Nearby Pits? | Y |
Nearby Fractures? | N |
Nearby Depressions? | N |
In Dome | Y |
Beside Dome | Y |
In Depression | N |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | N |
