Pits Atlas: Copernicus LB2
Impact Melt, Large Bowl pit: Copernicus | |
---|---|
Name | Copernicus LB2 |
Lat. | 10.0588 |
Long. | 339.8038 |
Desc. | Elliptical pit with very rounded floor (vertical walls are only ~15-20m high). Numerous 3-20m boulders in the interior, and there are several places where a slope runs from rim to center. No other features of note in the immediate area. |
Types | Large Bowl |
Terrain | Impact Melt |
Host Feature | Copernicus |
Funnel Min. Diam. | 325 |
Funnel Max. Diam. | 355 |
Inner Min. Diam. | 260 |
Inner Max. Diam. | 305 |
Azimuth | 140 |
Depth | 65.0 |
Depth 1 | 65.0 |
Depth 2 | N/A |
Depth 3 | N/A |
Best Stereo Left | M153014813L |
Best Stereo Right | M153014813L |
DTMs | |
Clipping Width | 700 |
Other IMGs | |
Data Warning | M1188488085L is the only non-slewed image with a shadow falling at the deepest point of the pit. |
Entrance Ramp | Y |
Overhang | ? |
Nearby Pits? | N |
Nearby Fractures? | N |
Nearby Depressions? | N |
In Dome | N |
Beside Dome | N |
In Depression | N |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | N |
