Name |
Copernicus LB5 |
Lat. |
10.2349 |
Long. |
339.6899 |
Desc. |
Elliptical pit with very rounded floor (vertical walls <20m high). Interior mostly only has boulders on the W side, and there is one break in the rim with a slope to the floor on the NW side. Slewed images show no overhangs. There are two PRFs near the rim |
Types |
Large Bowl |
Terrain |
Impact Melt |
Host Feature |
Copernicus |
Funnel Min. Diam. |
230 |
Funnel Max. Diam. |
290 |
Inner Min. Diam. |
220 |
Inner Max. Diam. |
270 |
Azimuth |
10 |
Depth |
50.0 |
Depth 1 |
50.0 |
Depth 2 |
N/A |
Depth 3 |
N/A |
Best Stereo Left |
M135324446R |
Best Stereo Right |
M135324446R |
DTMs |
|
Clipping Width |
600 |
Other IMGs |
M1136683665R, M1190842495L |
Data Warning |
M1188488085L is the only non-slewed image with a shadow falling near the deepest point of the pit (~20m E of deepest point). |
Entrance Ramp |
Y |
Overhang |
N |
Nearby Pits? |
N |
Nearby Fractures? |
N |
Nearby Depressions? |
N |
In Dome |
N |
Beside Dome |
Y |
In Depression |
N |
Colinear Pits |
N |
Colinear Depressions |
N |
Colinear Fractures |
N |
