Pits Atlas: Crookes 1
Impact Melt pit: Crookes | |
---|---|
Name | Crookes 1 |
Lat. | -10.2424 |
Long. | 194.7536 |
Desc. | A complicated and very large pit. There are three main sections: The east end is the deepest part, and does not have any slopes leading into it. It is separated from the central section by a jumble of 10-15m boulders. The central section is wide (70m across) and round-bottomed, and the south wall is a smooth slope to the floor. The western section is a narrow (50x17m) canyon, barely opening into the central section, and with a smooth slope from the west end down to the floor. There are deep fracture systems to the north and south, and some depressions/collapses past the east end. |
Types | |
Terrain | Impact Melt |
Host Feature | Crookes |
Funnel Min. Diam. | 77 |
Funnel Max. Diam. | 259 |
Inner Min. Diam. | 67 |
Inner Max. Diam. | 213 |
Azimuth | 70 |
Depth | 17.0 |
Depth 1 | 20.5 |
Depth 2 | 14.7 |
Depth 3 | 15.8 |
Best Stereo Left | M1214163158R |
Best Stereo Right | M1214163158R |
DTMs | |
Clipping Width | 500 |
Other IMGs | M176353098R |
Data Warning | All depths are of eastern section. Central section is >10m deep (M1097573241L), and western section is ~18m deep (M110316458R) |
Entrance Ramp | Y? |
Overhang | ? |
Nearby Pits? | N |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | N |
In Depression | N |
Colinear Pits | Y |
Colinear Depressions | Y |
Colinear Fractures | N? |
