Pits Atlas: Crookes 2
Impact Melt pit: Crookes | |
---|---|
Name | Crookes 2 |
Lat. | -10.1275 |
Long. | 194.7446 |
Desc. | A rectangular pit with a relatively enormous boulder filling ~80% of it. The boulder is roughly round, and stretches from NW wall to SE wall. The SW wall is a gentle slope that leads into a ~60x30m depression, and the SE wall may also be a slope. No floor visible, depths are from SW slope near boulder. In line with fractures 125 and 250 m to the SW, and there's another fracture/depression string ~100m north. |
Types | |
Terrain | Impact Melt |
Host Feature | Crookes |
Funnel Min. Diam. | 20 |
Funnel Max. Diam. | NA |
Inner Min. Diam. | 11 |
Inner Max. Diam. | 18 |
Azimuth | 45 |
Depth | 10.0 |
Depth 1 | 8.9 |
Depth 2 | 10.6 |
Depth 3 | 9.5 |
Best Stereo Left | M1214163158R |
Best Stereo Right | M1214163158R |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | |
Entrance Ramp | Y |
Overhang | ? |
Nearby Pits? | N |
Nearby Fractures? | Y |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | N? |
In Depression | Y |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | Y |
