Pits Atlas: Crookes 5c
Impact Melt pit: Crookes | |
---|---|
Name | Crookes 5c |
Lat. | -10.6824 |
Long. | 194.8646 |
Desc. | Wide collapse in the E side of a PRF, mostly filled with the semi-coherent remains of the former roof (shattered into 1-2m boulders, but there are still sections that look like they fell together). The E side is a smooth slope to the surrounding surface- no rim. ~10m to the W, across a strip of untouched ground, is another collapse. The arrangement is similar to the various not-bridges in King crater, and I cannot rule out the uncollapsed section being hollow (stereo image hints at a 1-2m overhang), but the rock pile on the W side of the "bridge-like" section appears solid. |
Types | |
Terrain | Impact Melt |
Host Feature | Crookes |
Funnel Min. Diam. | 38 |
Funnel Max. Diam. | 46 |
Inner Min. Diam. | 34 |
Inner Max. Diam. | 45 |
Azimuth | 25 |
Depth | 9.0 |
Depth 1 | 8.9 |
Depth 2 | 8.8 |
Depth 3 | 10.0 |
Best Stereo Left | M176359843L |
Best Stereo Right | M176359843L |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | |
Entrance Ramp | Y |
Overhang | Y? |
Nearby Pits? | Y |
Nearby Fractures? | N |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | Y |
In Depression | N |
Colinear Pits | Y |
Colinear Depressions | N |
Colinear Fractures | N |
