Pits Atlas: Crookes 7
Impact Melt pit: Crookes | |
---|---|
Name | Crookes 7 |
Lat. | -10.5592 |
Long. | 194.823 |
Desc. | Round pit in the SW flank of a blocky rise. Appears to have somewhat rounded floor, with only one or two ~1m boulders. Pit is in shadow in full stereo pair, but higher-Sun slewed image shows no overhang on W wall. E wall (under the rise) is never seen. E rim is ~12m higher than W rim above floor. No other collapses in the area. |
Types | |
Terrain | Impact Melt |
Host Feature | Crookes |
Funnel Min. Diam. | 23 |
Funnel Max. Diam. | 23 |
Inner Min. Diam. | 19 |
Inner Max. Diam. | 20 |
Azimuth | 55 |
Depth | 8.0 |
Depth 1 | 8.6 |
Depth 2 | 6.6 |
Depth 3 | 8.2 |
Best Stereo Left | M176359843R |
Best Stereo Right | M176359843R |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | All measurements are from W rim. Depth from E wall measure in M1119966613L is ~23m. |
Entrance Ramp | N |
Overhang | ? |
Nearby Pits? | N |
Nearby Fractures? | N |
Nearby Depressions? | N |
In Dome | Y |
Beside Dome | N |
In Depression | N |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | N |
