Pits Atlas: Crookes 11b
Impact Melt pit: Crookes | |
---|---|
Name | Crookes 11b |
Lat. | -10.2372 |
Long. | 194.7822 |
Desc. | Rectangular pit, southern of the Crookes 11 pair. SW wall is a slope to floor level, and the floor is mostly clear of boulders. |
Types | |
Terrain | Impact Melt |
Host Feature | Crookes |
Funnel Min. Diam. | 34 |
Funnel Max. Diam. | 55 |
Inner Min. Diam. | 26 |
Inner Max. Diam. | 28 |
Azimuth | 30 |
Depth | 9.0 |
Depth 1 | 9.8 |
Depth 2 | 6.5 |
Depth 3 | 12.0 |
Best Stereo Left | M176359843R |
Best Stereo Right | M176359843R |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | Depth 2 is from (lower?) W rim. |
Entrance Ramp | Y |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | N? |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | Y |
In Depression | N |
Colinear Pits | Y |
Colinear Depressions | Y? |
Colinear Fractures | N |
