Pits Atlas: Das 1a
Impact Melt pit: Das | |
---|---|
Name | Das 1a |
Lat. | -26.3088 |
Long. | 223.2603 |
Desc. | A narrow pit in the floor of a sinuous round-bottomed depression, oriented parallel to the depression. NW wall is collapsed to form a slope from rim to SE wall. 25 m from Das 1b |
Types | |
Terrain | Impact Melt |
Host Feature | Das |
Funnel Min. Diam. | NA |
Funnel Max. Diam. | NA |
Inner Min. Diam. | 5 |
Inner Max. Diam. | 21 |
Azimuth | 135 |
Depth | 11.0 |
Depth 1 | 9.4 |
Depth 2 | 11.6 |
Depth 3 | >15.0 |
Best Stereo Left | M112489524L |
Best Stereo Right | M112489524L |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | North (shadow-casting) wall has some protruding rocks part-way down (~7m below rim?), and depths 1 and 2 are from those rocks. Depth 3 is from rim of host depression to south wall (no floor visible). Stereo pair is accidental, may not produce useful DTM. |
Entrance Ramp | Y |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | N |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | Y |
In Depression | Y |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | N |
