Pits Atlas: Das 3
Impact Melt pit: Das | |
---|---|
Name | Das 3 |
Lat. | -26.2963 |
Long. | 223.0729 |
Desc. | Roughly rectangular pit. There is some degree of collapse on the south wall, but it does not appear to reach the floor. The floor itself has some non-flatness. There is a shadow edge visible in the slewed image M176171262L that is not visible in the slightly higher-Sun nadir image M1183360718L, indicating a >=2 m deep overhang. There is a small (~3m diameter) depression/pit 70m to the NW, a NNW/SSE-trending linear depression ~300m W, and several other possible depressions running in the same direction in the area. |
Types | |
Terrain | Impact Melt |
Host Feature | Das |
Funnel Min. Diam. | 21 |
Funnel Max. Diam. | 23 |
Inner Min. Diam. | 13 |
Inner Max. Diam. | 18 |
Azimuth | 145 |
Depth | 6.0 |
Depth 1 | 6.0 |
Depth 2 | >8.0 |
Depth 3 | >8.0 |
Best Stereo Left | M176178010R |
Best Stereo Right | M176178010R |
DTMs | |
Clipping Width | 200 |
Other IMGs | |
Data Warning | Floor is only visible in Depth 1 image (and an unused slewed image). Depths 2 and 3 and minimum values. |
Entrance Ramp | N? |
Overhang | Y |
Nearby Pits? | Y? |
Nearby Fractures? | N |
Nearby Depressions? | Y? |
In Dome | N |
Beside Dome | N |
In Depression | N |
Colinear Pits | N |
Colinear Depressions | Y |
Colinear Fractures | N |
