Chang'e 4 Rover Comes into View

4x enlargement, Chang'e 4 lander and rover
The Chang'e 4 rover is now visible to LROC! Just beyond the tip of the right arrow is the rover and the lander is to the right of the tip of the left arrow. The image appears blocky because it is enlarged 4x to make it easier to see the two vehicles. North is to the upper right, LROC NAC M1303570617LR [NASA/GSFC/Arizona State University].

On 30 January LROC acquired a spectacular limb shot centered on the Chang'e 4 landing site, looking across the floor of Von Kármán crater. At the time, LRO was more than 200 kilometers from the landing site so Chang'e 4 was only a few pixels across and the rover was not discernable. The following day LRO was closer to the  site and again slewed (59° this time) to capture another view. This time the small Yutu-2 rover shows up (two pixels) just north of the lander. Also, shadows cast by the lander and rover are now visible.

Chang'e 4 lander and rover seen obliquely
Chang'e 4 lander (near tip of left arrow) and rover (near tip of right arrow) nestled among craters on the floor of Von Kármán crater. Image is 1700 meters (5580 feet) wide across the center, LROC NAC  M1303570617 [NASA/GSFC/Arizona State University].

At some time after the formation of Von Kármán crater, the crater floor was covered by eruptions of basaltic lava, similar to the eruptions in Hawaii last summer. Chang'e 4 will collect compositional measurements of these farside basaltic rocks, and lunar scientists are anxiously awaiting these results. Do volcanic rocks on the farside differ from the basalts collected from the nearside? We will have to wait and see!

A striking aspect of the floor of Von Kármán crater is the number and variety of impact craters. There is a high density of craters because the surface is more than 3 billion years old! During those 3 billion years, so many small craters (<200 meters (660 feet) in diameter) formed that when a new one forms, the total number of craters does not increase. This seemingly counterintuitive situation occurs because each new crater erases, on average, one older crater of comparable size, a state known as "equilibrium" to crater counting geologists. For surfaces this old (in equilibrium), only larger craters (>1000 meters (3280 feet) diameter), which are not in equilibrium, continue to increase in density and can be used to estimate the age of the surface.

Note also all of the small craters that have formed on top of larger ones. Smaller impacts wear down and degrade larger craters over time. You can easily see a wide variety of crater degradation states, ranging from sharp and crisp (new) to highly degraded (old). As result of all of these impacts (small and large), the surface of the Moon consists of a very fine powder known as regolith, in which the Apollo astronauts made their distinct boot prints. Explore the variety of craters across the floor of Von Kármán crater in the full NAC image (below).
