Pits Atlas: Tycho 5e
Impact Melt pit: Tycho | |
---|---|
Name | Tycho 5e |
Lat. | -42.6218 |
Long. | 348.6372 |
Desc. | Square pit, off the line of the other Tycho 5 pits (100m SE of Tycho 5a). SW wall is a smooth slope down to where it gets hidden by the shadow from the north wall |
Types | |
Terrain | Impact Melt |
Host Feature | Tycho |
Funnel Min. Diam. | 19 |
Funnel Max. Diam. | 20 |
Inner Min. Diam. | 14 |
Inner Max. Diam. | 15 |
Azimuth | 60 |
Depth | 5.0 |
Depth 1 | 5.4 |
Depth 2 | 5.3 |
Depth 3 | N/A |
Best Stereo Left | M1206074763R |
Best Stereo Right | M1206074763R |
DTMs | |
Clipping Width | 200 |
Other IMGs | M111661378L |
Data Warning | |
Entrance Ramp | Y |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | N |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | N |
In Depression | N |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | N |
