Pits Atlas: Copernicus 6a
Impact Melt pit: Copernicus | |
---|---|
Name | Copernicus 6a |
Lat. | 10.1053 |
Long. | 339.995 |
Desc. | Larger and northernmost of a linear pair (triplet?) of pits at the north end of a subtle linear depression (>300m long). This pit is triangular, with the longest side(?) parallel to the line of the pits. Both pits are within a larger linear collapse (pit?) and are only distinguishable as distinct pits at the very highest Sun angles (funnel measurements for both are for the enclosing depression). Copernicus 6a is ~4m NW of Copernicus 6b, and there is another collapse just SE of 6b (although it might just be walls of the surrounding depression). There are no other pits in the immediate vicinity. |
Types | |
Terrain | Impact Melt |
Host Feature | Copernicus |
Funnel Min. Diam. | 30 |
Funnel Max. Diam. | 55 |
Inner Min. Diam. | 9 |
Inner Max. Diam. | 10 |
Azimuth | 150 |
Depth | 11.0 |
Depth 1 | 8.9 |
Depth 2 | 12.2 |
Depth 3 | 12.8 |
Best Stereo Left | M144755352L |
Best Stereo Right | M144755352L |
DTMs | |
Clipping Width | 200 |
Other IMGs | M168333206L |
Data Warning | All depths are from very high Sun |
Entrance Ramp | N |
Overhang | ? |
Nearby Pits? | Y |
Nearby Fractures? | N |
Nearby Depressions? | Y |
In Dome | N |
Beside Dome | Y |
In Depression | Y |
Colinear Pits | N |
Colinear Depressions | N |
Colinear Fractures | N |
